CC-1 Multifunction Obstetric Chair

CC-1 multifunction obstetric chair is a kind of medical equipment for the diagnostic examination and clinical operation in obstetric and gynecological department, and is a special chair for woman to give birth,It is also possible for the mother and the newborne baby sleeping together after birth so that good nursing can be guaranteed.CC-1 obstetric chair is composed of two individual tables,one is for body while the other is for legs.The table is manually operated from one side to achieve demanded position.The adjustment of height is conducted through a hydraulic system while other movements are driven by special designed mechanism. Because of its reliability, easiness for operation and a wide selection of functional accessories, it is an ideal obstetric chair.

• Two in one type,CC-1 includes a body-table and a leg-table
• Hydraulic system for height and manual control for table positions
• Body-table can be postured to meet most of clinical demands
• Super width to enable baby and mother sleep together
• Stainless steel rails and accessories
• Detachable mattress easy for cleaning and disinfection

• The height adjustment of body-table:650~ 800mm
• Back section adjustment: Upwards -5~45°
• Abdomen section adjustment: Upwards -8~20° , Downwards 0~8°
• Body-table and leg-table is detachable and can be connected in way of plug-in.
• Both the body-table and leg-table have brakes to stop in a still position.
• Dimension of table board:
          body-table 1350× 650mm
          Leg-table 800× 550mm
          Overall-Length 2150mm
