JT-2A Operating Table for Multi-Applications |
|
The new JT -2A operating table has been designed with end-users in mind,The built-in multiple functions makes it possible to be used in general surgery and many specialized surgical procedures. Its functional design includes a hydraulic pump and spring gas cylinder system which is manually operated to provide smooth operation and easy positioning to meet most of surgical demands. A special high pressure laminate table board permits x-ray examination and fluoroscopy. With its wide selection of accessories JT -2A is a most useful and economical surgical table for OR |
| Technical Data |
• Maximum width: 480mm
• Length: 1960mm
• Height adjustment range: 710 -850mm
• lateral tilt: -15-+15 degrees
• Head section adjustment: -40-+30 degrees,detachable
• Back section adjustment: 0-+75 degree
• Leg section adjustment: -90-0 degree,detachable
• Gross weight: 288kg
• Dimensions: 1770×770× 940cm |
| Standard Composition |
Mattress |
1 set |
Anaesthesia screen |
1 set |
Cassette tray |
1 set |
Cassette shaft |
1 set |
Body supports |
1 set |
(Shoulder supports) |
1 set |
Leg support |
1 set |
Single-sheet arm rest |
1 set |
Bodyrestraint straps |
1 set |
Cushions |
1 set |
Handle for kidney bridge |
1 set |
|
| Optional accessories |
Double-arm rest |
|
Neurosurgery head rest |
|
Tractor for orthopedics |
|
Rack for cerebral surgical |
|
Accessory rack |
|
|
Picture |
| |
|
